BPTT for RNN

Back Propagation Through Time (BPTT)



States computed in the forward pass must be stored until they are reused during the backward pass, so the memory cost is also O(τ).

https://mmuratarat.github.io/2019-02-07/bptt-of-rnn



Loss function

https://mmuratarat.github.io/2019-02-07/bptt-of-rnn

Let's say we are using cross-entropy loss

Derivative of loss with respect to Wyh

https://mmuratarat.github.io/2019-02-07/bptt-of-rnn

derivative of cross entrophy loss w.r.t. ot is (yt^ - yt)

derivative of cross entrophy Loss w.r.t. softmax and derivative of output(t) w.r.t. Wyh

Derivative of loss with respect to Bias by



https://mmuratarat.github.io/2019-02-07/bptt-of-rnn

Derivative of loss with respect to hidden state

at the time-step t+1, we can compute the gradient and further use backpropagation through time from t+1 to 1 to compute the overall gradient with respect to Whh

https://mmuratarat.github.io/2019-02-07/bptt-of-rnn

Aggregate the gradients with respect to Whh over the whole time-steps with backpropagation,



https://mmuratarat.github.io/2019-02-07/bptt-of-rnn

Derivative of loss with respect to Wxh

at the time-step t+1

https://mmuratarat.github.io/2019-02-07/bptt-of-rnn

we can take the derivative with respect to Wxh over the whole sequence as

https://mmuratarat.github.io/2019-02-07/bptt-of-rnn



vanishing gradient and exploding gradient

large increase in the norm of the gradient -> explode

opposite -> vanish, making it impossible for the model to learn correlation between temporally distant events.

그래서 backpropagate되는 gradient들을 적당히 끊어주는 truncated rnn을 사용할 수있다.

이런 이유로 LSTM, GRU가 대체로 많이 사용된다.
